Choose the location result you need

On a small screen, scroll sideways to read both columns.

Passive UHF readers often support checkpoint and inventory workflows. Powered tags and locating infrastructure can support other approaches, including UWB real-time locating systems. Available combinations vary; request the complete hardware, software, installation and service scope.

The omlox locating guide (2024, PDF) describes a UWB core zone and complementary location technologies connected through a common data layer. This is an interoperability architecture, not a promise that every technology delivers identical location precision.

Define quality before comparing demonstrations

Choose a reference appropriate to the claim. A room-level system can be compared against independently recorded room occupancy. A coordinate system needs reference positions in the same coordinate frame, with a reference uncertainty small enough for the intended comparison. Another unverified tracker is a weak reference.

For coordinate results, measure the distance between the estimated and reference positions at matched times. Use horizontal error for a two-dimensional claim and a clearly defined three-dimensional measure when height matters. Report how errors vary across the site, rather than only the best point or average.

Freshness is separate from spatial error. Distinguish the time the location was observed from the time an application received or displayed it. State the maximum acceptable age for the task and what the interface shows after that age. Clock offsets and buffering can otherwise make old data look current.

Run a representative search trial

1. List assets, tag positions, areas and the decisions being tested. Include metal cabinets, crowded storage and other conditions the normal workflow encounters.
2. Define planned routes or independently chosen check times. Record the reference location and time before comparing the system result.
3. Repeat with representative orientations, loading, people and traffic. Include boundary crossings and pauses near neighboring zones.
4. Save all scheduled checks, including wrong, stale and missing results. Record battery state, infrastructure changes and service interruptions where relevant.
5. Give a user the displayed information and measure whether the correct asset is found within the task’s agreed time. Record the manual search needed when the system is uncertain.

Keep “last seen in Room A” visibly different from a fresh observation in Room A. When an asset crosses a boundary, define the evidence needed to change its displayed zone and how temporary ambiguity is represented. Smoothing can stabilize a display while increasing the time before a move appears.

A strong handheld signal can guide a search, but its relationship to distance depends on the environment and tag orientation. Validate the actual search procedure rather than translating a signal indicator into an unsupported meter reading.

Maintain the link between tag, asset and location

Record tag attachment, reassignment and replacement. A detached tag can still be located while the asset is elsewhere. Include periodic checks of the physical association in the maintenance plan. For powered devices, plan battery service and identify who receives a low-battery or missing-tag exception.

Retain the coordinate frame, units and floor/zone definitions in exports and integration documentation. When a map changes, version it and retest affected boundaries. A location value without its frame and timestamp can be difficult to interpret correctly in another application.

Test reader or anchor loss, communications outages and application recovery. Confirm how the system reports degraded coverage and reconciles delayed observations. The RFID integration guide explains why an observation and a committed business event require separate handling.

An asset near a loading bay may be waiting, being repaired or already assigned to a shipment. Use workflow evidence to confirm the business state. Similarly, location systems used around people need defined purposes, appropriate access and retention; an asset-search project should not silently become a staff-performance tracker.

Compare deployments by successful search tasks, coverage, maintenance and exception effort. Keep a record of the conditions under which the result was accepted so a changed floor plan or asset type has a clear retest path.

Take the guide into your workflow

Download the working checklist (plain text). The editable text file includes its purpose, instructions, evidence fields and a link back to this guide. Record observed results and unresolved questions before making the decision.
